Type B (truck) OBD-2 cable to Sub-D
[090117]
13,50EUR*
inkl. MwSt.
zzgl. Versandkosten
Item is in stock.

Standardized version. Length: 1 m

Particularly ergonomic OBD-2 plug (according to SAE J1962/ISO 15031-3 standard with hurrying ahead ground at pin 4 and 5) to 9-pole serial Sub-D jack (female).

Stable, industrially manufactured execution with molded plugs.

Conforming to standards with discontinued centre bar of type B (truck with 24 Volt).

The cable is not suitable for the direct connection between vehicle and computer - an interface is needed.

Pinout:
Sub-DOBD IIDescription
15Signal ground
24Chassis ground
36CAN High
47ISO 9141-2, K-Line
514CAN Low
610J1850 Bus -
72J1850 Bus +
815ISO 9141-2, L-Line
916Battery voltage

Discounts
Number       Discount    Unitprice
from 100    5%    12,83EUR*
