Ptit USBTTL - FTDI USB to TTL serial adapter (without jack)
[150400]
17,06EUR* 3,48EUR*
inkl. MwSt.
zzgl. Versandkosten
Item is in stock.
3.48EUR*

Very small USB to TTL serial adapter with original FTDI FT232RQ Chip in QFN-32 package.

Attention: There is no USB socket on the board. This can possibly be soldered itself or wires are connected.

The interface is just about ca. 24,13 x 21,59 mm in size, yet offers all the features that are required:
  • no Micro USB connector mounted, no Jumper included
  • Optional (jumper selectable) 3.3 V or 5 V TTL signal level and operating voltage
  • 2.54 mm pin header for connection of relevant signals VCC, GND, TxD and RxD
  • In addition, 12 solder pads for further important signals
  • 3 LEDs (red, green, yellow) for power, receiving data and send data
  • 2 mounting holes for attaching the Interface

Ideal for Arduino, Rasperry Pi (RPI) and own projects.

Kurzanleitung (PDF)

website FTDI datasheet FT232R, driver
