Complete kit for an OBD II LCD Model d
Project description: http://www.blafusel.de/obd/obd2lcd_d.html
Supported OBD II protocolls: ISO 9141, ISO 14230 (KW 2000), ISO 15765 (CAN)
Video on YouTube
List of already tested vehicles: http://carlist.blafusel.de. Use the borrowing service, in order to examine whether the display works at your vehicle. Function warranty only on of us tested vehicles/controllers.
Color LCD: blue/white or white/black or green/black (select with the order options, please!).
Content:
- Printed circuit board
- Complete construction unit set
- Microcontroller fully programmed
- Case
- OBD-2 Connector
While driving see permanently relevant measured values from your vehicle and be warned when errors occurrence automatically.
- Up to eight values at the same time nearly in real time - individually configurable
- Depending upon vehicle:
- Vehicle speed (material and without the inaccuracy of the normal Tachos)
- Engine speed
- Coolant temperature (in diesel fuel cars often oil temperature)
- Air intake temperature
- Engine load value
- Ignition timing advance
- Absolute throttle position
- O2 Sensor
- Supported OBD standard
- and more ...
- In two languages: German/English at any time selectable
- Alert if error stored (DTC)
- Display stored error-codes and clear DTCs
- Battery voltage
- Acceleration measurement 0..100 km/h
- Momentary consumption gauge (experimental)
- adaptive brightness control
- Intendes for modern blue or white Display
Complete construction unit set for OBD II LCD Model C:
Carefully arranged construction unit assortment for the display. Contain all necessary construction units for the assembly on the printed circuit board.
Content:
| Anzahl |
Bezeichner |
Typ |
| 1 | R1 | 510 Ω (grün - braun - schwarz - schwarz) |
| 2 | R2, R5 | 10k Ω (braun - schwarz - orange) |
| 1 | R4 | 22k Ω (rot - rot - orange) |
| 1 | R6 | 18 Ω (braun - grau - schwarz) bzw. 4,3 Ω |
| 1 | R7 | 3,3k Ω (orange - orange - rot) |
| 2 | R9, R10 | 1k Ω (braun - schwarz - rot) |
| 1 | R11 | 270 Ω (rot - violett - braun) |
| 2 | R12, R13 | 100 Ω (braun - schwarz - braun) |
| 1 | R8 | 2,5k Ω bzw. 10k Ω Poti |
| 1 | R3 | 250 Ω Poti |
| 1 | C1 | 22µ/35 |
| 1 | C2 | 220µ/6,3 |
| 1 | C3 | 10µ/16 |
| 4 | C4, C5, C7, C8 | 22p |
| 2 | C9, C10 | 560p |
| 1 | C6 | 100n |
| 1 | D1 | 1N4004 |
| 1 | D2 | 1,5KE18A |
| 1 | D3 | SB130 |
| 1 | D4 | SFH309 |
| 1 | T1 | BC547 |
| 1 | F1 | MF-R 0,2A |
| 1 | IC1 | MC33290 |
| 1 | IC2 | LM2574-5 |
| 1 | IC3 | ATmega644 |
| 1 | IC4 | PCA 82C250/MCP 2551 |
| 1 | IC5 | MCP 2515 |
| 1 | L1 | 47µH/450mA (gelb - violett - schwarz) |
| 1 | L2 | 680µH/150mA (blau - grau - braun) |
| 1 | LCD | EA DIP204-4NLED/EA DIP204B-4NLW/EA DIP204J-4NLW |
| 1 | LED | LED 3 mm |
| 2 | Q1, Q2 | 16MHz |
| 1 | S1 | Kurzhubtaster 13 mm |
| 2 | TEMP1, TEMP2 | LM 335 |
| 1 | BUZZ | TDB05 |
| 1 | JP1 | 6x Stiftleiste |
| |
| Montagematerial: 2 m sechsadriges Kabel, 4 Beilagscheiben, 2 Schrauben, 1 Kabeldurchführung |
